MC6-GUIDABLE PARACHUTE SYSTEM
It was designed to provide paratroops a precise infiltration. MC-6 is furnished with the latest advanced design for guidable paratroops. It was developed through the SOFTAPS software (Assault Parachutes System-Tactical Operations Special Forces.
MC-6 SUB-SYSTEMS
MC-6 is a three sub-systems combination: Main Cupola SF-10A, T-11R Reserve, and T-11 trappings.
Information for Ordering
Specifications | MC-6 | MC1-1C |
---|---|---|
OTAN Paratroops Group Reference | 11-1-7400 | 11-1-900-2 |
Inventory Number | 1670-01-527-7537 | 1670-01-262-2359 |
Nominal Diameter | 32 ft / 9.8 mts | 5ft / 10.7 mts |
Sections Number | 28 | 30 |
Cupola Material | PIA-C-44378 T4, nylon low porosity | MIL/ PIA-C-44378 T1, nylon, low porosity |
Standard color | Green leaf motif | Green leaf motif |
Suspension Line
Specifications | MC-6 | MC1-1C |
---|---|---|
Material | PIA-C-5040 type II | PIA-C-5040 type II |
Length | 21.3 ft / 6.5m | 22ft / 6.7m |
Tension Length | 400lb / 1780N | 400lb / 1780N |
360° turn duration | 5 seconds | 9 seconds |
Assembled Weight | 29 pounds / 13kg | 29 pounds / 13kg |
Maximum Starting Weight | 400lb / 181kg | 360lb / 163kg |
Minimum Starting Height | 500 ft / 152m | 500 ft / 152m |
Maximum Starting Speed | 150 KEAS | 150 KEAS |
