T11 – NON GUIDABLE PARACHUTE SYSTEM
The non guidable T-11 troops parachute was developed for today´s warrior. It substitutes T-10 parachute, which has been in service for more than 50 years.
T-11 was specifically designed by Airborne Systems to land safely a 400 pounds paratrooper.
With a minimum opening impact, a slow dropping rhythm and zero swinging effect, jumper is provided with a higher level of security, and a successful accomplishment in the combat mission.
This new-design parachute can be fit from fifth female percentile to 97th male percentile body sizes
Order Information
(T-11 Main and T-11R Reserve Parachute inclusive)
Part number | Z |
---|---|
NSN | 1670-01-539-4525 |
Diameter | 28.6 ft 8.72 mts |
Dropping speed at Sea Level
400 lb (181.4 kg) AUW | <18ft s/sec<5.48 mts/sec |
---|---|
Main Parachute Weight | 36.8lb 16.56kg |
Aircraft Maximum Speed | 150 KIAS 278 km/h |
Maximum Weight | 400 lbs / 180 Kg |
Oscillation Angle | Less the 5 degrees |
Deployment Height – Above Sea Level (A.S.L.)
Minimum | 500 ft ± 12 5 ft 152.4 mts ± 38.1 mts |
---|---|
Maximum | 7500 ft 2.286 mts |
Useful Life | 15 years useful life; 12 years of service |
Repack | 120 days |
