T-SIGHT-RS13
Our reflex-style thermal sight, T-SIGHT-RS13 series features an advanced VOX detector in conjunction with a Matrix III allegorism to obtain high quality thermal images and be projected on its 3cm eyepiece.
This sight can operate in extreme temperatures, has easy access buttons even when gloves are used and is easily mounted on a picatinny rail.
Its components are protected by a metal housing using space aluminum designed for rough handling and shock resistant with the ability to withstand G forces from the recoil of weapons.
Parameters
Dimension | (length 80.5mm x width 46/51mm x height 73mm, tolerance +/-2mm |
---|---|
Weight | 235 g +/- 5g |
Battery | 1 x CR123 |
Battery Life | Up to 3.5 hours |
Laser | 650nm |
IP Rating | IP67 |
Characteristics
Description | RS13 |
---|---|
Resolution | 320 x 280 |
Frame x sec | 25Hz |
Pixel size | 17µm |
Detection | (1.7 x 0.5m) 475m |
Start time | ≤ 3 sec |
Sensor | VOX |
Objective lens | 13mm |
FOV | 28.4 ° x 21.4 ° |
Gain | 1x – 4x |
Mount | Picatinny |
Connectivity | Type C |
Function
Polarization Image | Hot black, hot white, bright red and pseudo color |
---|---|
Image Calibration | Background calibration / shutter calibration / image brightness / sharpness / contrast adjustment. |
